Acoem Machine Defender Machinery Diagnostic

$3,900

In Stock

Manufacturer: ACOEM
Model: Machine Defender
Included: Wireless, triaxial, piezoelectric, accelerometer (compatible with FALCON, iOS and Android systems), USB charger for wireless sensor, USB cable for wireless sensor, Two rail magnet for wireless sensor, Belt pouch, Limited lifetime warranty, No annual maintenance fees, Software and firmware updates (life of tool)

Acoem Machine Defender is compatible with both IOS and Android smartphones and tablets. It seamlessly connects with our wireless triaxial piezoelectric sensor, offering plant personnel a straightforward and efficient method to monitor machine health.

Instant feedback is provided through green, yellow, and red indicators, alerting users to bearing health, misalignment, and unbalance issues. This system is ideal for maintenance and operations teams requiring quick assessments of machine conditions on the go.

Dive into your machine’s health with instant advice on bearing and other faults using a wireless, triaxial, piezoelectric, sensor with this Acoem Machine Defender app-based system.

Acoem Machine Defender Features

Accurex™ Ai: Patented AI solution that provides immediate, easy-to-understand machine diagnostics.
Wireless Sensor: Tri-axial and piezoelectric
Other/Additional Functions: ISO 10816-3 machinery classification
Capabilities: Smart evaluation of bearing health, misalignment, unbalance, machinery diagnostic
Thoughtfully Designed: Tablet-based app is compatible with Falcon, iOS and Android systems
Streamlined Process: Save time with automatic measurement setup and report or share results through email, or text message

Acoem Machine Defender – What is Included

Wireless, triaxial, piezoelectric, accelerometer (compatible with FALCON, iOS and Android systems)
USB charger for wireless sensor
USB cable for wireless sensor
Two rail magnet for wireless sensor
Belt pouch
Limited lifetime warranty
No annual maintenance fees
Software and firmware updates (life of tool)

Acoem Machine Defender Specifications

Hardware Type Reference	CAC1008000
Metrology – Acoem Machine Defender
Three axial measurements	Synchronous acquisition in X, Y and Z directions
Sampling frequency	51.2 kHz on all axes ( Fmax 20 kHz ) Sensing element – Piezoelectric / Annular shear mode
Sensing element internal sensitivity, 24 °C	100 mV/g (numerically converted)
Sensitivity adjustment	Factory-calibrated and adjusted
Full scale	80 g
Signal-to-Noise ratio	> 80 dB Amplitude non-linearity – 1% max
Frequency response after triaxial mechanical assembly	± 3 dB (Z) – 0.4 Hz – 15 kHz
Full bandwidth	20 kHz on all axes Accuracy- +/- 5% @ 120 Hz, 1 g
Transverse response sensitivity (120 Hz, 1 g)	< 5% ( < -26 dB )
Electrical noise, nominal – Broadband 0 Hz–5 kHz – > 1 Hz – Peak velocity (after 1 integration)	– < 5 mg – < 20 μg/√Hz – < 0.13 mm/s
Physical – Acoem Machine Defender (for Machinery Diagnostic)
Dimensions	Ø42 x H116 mm Weight – 373 g
Mounting	M6 threaded hole Housing material – Stainless steel
Environmental
Operating temperature range	-20°C to 60°C Resistance to shocks – 5,000 g peak
Resistance to continuous Vibration	500 g peak Protection – IP65
Battery – Acoem Machine Defender
Type	Li-Ion
Operating lifetime	8 hours
Rechargeable	By USB ( power supply adapter in standard delivery )
Charging time	~8 hours with the standard 500 mA charge current
Automatic stand-by	After 10 min if no connection has been established
Communication
Wireless protocol	Wi-Fi Point to point
Typical wireless range	Up to 25 meters line of sight depending on the environment
Wi-Fi communication channel	User setting: 1, 6, 11 Sync protocol – Proprietary
Standard mobile systems compatibility	iOS ( 9.3 or sup. ) , Android ( 4.4.2 or sup. )
Patented Technology – Acoem Machine Defender
Patent Number	US 9,921,136
Radio certifications	EC, FCC, IC, MIC ( Japan )
