OLYMPUS DP 4000 XRF Analyzer
$3,500
In Stock
- Manufacturer: Olympus
- Model: DP 4000
- Included: Docking Station, AC Adapter/Charger, Power Cord, USB PC Interface Cable, Wrist Strap For Unit, User Manual On CD-ROM, Hard Carrying Case
Description
OLYMPUS DP 4000 XRF Analyzer is the ideal handheld XRF analyzer for ultra quick, analytically demanding applications such as trace levels and light elements in low alloy steel, soil, mining, and metallurgical samples.
The DP 4000 Delta Premium OLYMPUS XRF Analyzer large area SDD and advanced 4W application optimized X-ray tube provide tremendous speed and superior light element analysis in air.
Incorporating everything you need in a handheld XRF analyzer with stateof-the-art innovations and a rugged design – the DELTA Line.
OLYMPUS DP 4000 XRF Analyzer Features:
- Powerful 4W X-ray tube, 200 µA current (max), optimized beam settings
- Tight geometry for exceptional LODs and high analysis throughput
- Large-Area SDD and customized X-ray tube options for exceptional sensitivity and precision for more elements and materials
- Patent-pending automatic barometric pressure correction that adjusts calibration as needed for more accurate analysis of light element
- OLYMPUS DP 4000 XRF Analyzer Lightning-fast data acquisition for faster testing time
- Floating Point Processor: Provides more calculations in less time, and leverages more advanced calibration algorithms
- Integrated Bluetooth® for data input and output available in most countries
- Integrated wide area heat sinks throughout the DELTA body for high power use in extreme temperatures
- Analysis indicator lights visible from 360° to help ensure safe use
- Advanced colortouch LCD screen for clarity, brightness, responsiveness, and energy efficiency for indoor/outdoor use
- Accelerometer technology puts the unit into sleep mode to save energy when not in use; logs impacts for tool management
- DELTA PC Software for enhanced data analysis, calibration modeling, and optional closed beam workstation operation
- USB interface port for high-speed downloads and seamless PC control
- Ergonomic rubberized handle for enhanced grip
- Docking Station and Hot Swap Batteries
OLYMPUS DP 4000 XRF Analyzer Included:
- Docking Station
- AC Adapter/Charger
- Power Cord
- USB PC Interface Cable
- Wrist Strap For Unit
- User Manual On CD-ROM
- Hard Carrying Case
OLYMPUS DP 4000 XRF Analyzer Specifications:
| Weight | 1.5 kg (3.25 lbs) without battery |
| Dimensions | 260 × 240 × 90 mm (10.25 × 9.5 × 3.5 in.) |
| Excitation source | 4W Rh, Au, or Ta anode (per application) X-ray tube |
| Detector | Large-Area Silicon Drift Detector |
| Environemntal temperature range | -10 ºC to 50 ºC (14 ºF to 122 ºF) |
| Analytical range | Alloy and Mining: Mg and up for Rh/Ag and Al and up for Ta/Au; Soil: P and higher |
| Processing electronics | 530 MHz CPU with integrated FPU with 128 MB RAM; Proprietary Olympus X-act Count Digital Pulse Processor (DPP) |
| Smart electronics | Accelerometer; Barometer for atmosphere pressure correction of light elements’ measurements |
| Power | Rechargeable Li-ion battery; Hot-swap maintains analyzer power during battery change |
| Display | 32 bit Color QVGA resolution, Blanview transmissive backlit touchscreen; 57 × 73 mm (2.25 × 2.9 in.) |
| OLYMPUS DP 4000 XRF Analyzer Data storage | 1 GB microSD (stores ~75,000 readings) |
| Data transfer | USB, Bluetooth |
